T-REX Series
T-REX- 10KLP3G01
10kW
Low Voltage
2MPPTs
Hybrid
Three Phase
Product Introduction
T-REX-10KLP3G01 is a multifunctional inverter, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size, Its comprehensive LCD display offers user configurable and easy accessible button operation such as battery charging, AC/solar charging, and acceptable input voltage based on different applications.
Product Advantages
● 48V low voltage battery,transformer isolation topology.
● Built-in WiFi for real-time monitoring.
● IP65 Protection Level.
● Switch power supply within 20ms.
● Support storing energy from diesel generator.
● Easily upgrade the existing solar system with AC coupling.
● Built-in WiFi for real-time monitoring.
● IP65 Protection Level.
● Switch power supply within 20ms.
● Support storing energy from diesel generator.
● Easily upgrade the existing solar system with AC coupling.
Model
T-REX-10KLP3G01
Rated Output Power
10kW
Nominal DC Input Voltage
40V~60V
Nominal Input Voltage
L1/L2/L3/N/PE,230/400Vac
Nominal Grid Frequency
50/60Hz
Protection Degree
IP65
Operating Temperature
-25°C~60°C,>45°C Derating
Download
- T-REX-10KLP3G01 Inverter User Guide - English
- Warranty T&Cs-T-REX-10KLP3G01 Policy - English
- ES-Manual_T-REX-10KLP3G01 Guía del usuario - Español
- UKR-Manual_T-REX-10KLP3G01 Посібник користувача - Українська
- FR-Manual_T-REX-10KLP3G01 Guide utilisateur - Français
- PL-Manual_T-REX-10KLP3G01 Instrukcja obsługi - Polski
- RUS-Manual_T-REX-10KLP3G01 Руководство пользователя – Русский
- T-REX-10KLP3G01 Benutzerhandbuch - Deutsch
- [Certyfikat zgodności] T-REX-10KLP3G01 Poland Listing Certificate
- [CERTIFICATE OF CONFORMITY] T-REX-10KLP3G01 VDE 4105 Cert Germany
- [CERTIFICATE of Conformity] T-REX-10KLP3G01 NC RfG & PSE Poland Polish grid connection regulations Cert
- [CERTIFICATE OF CONFORMITY] T-REX-10KLP3G01 LVD Germany
- [CERTIFICATE OF CONFORMITY] T-REX-10KLP3G01 EN50549 EU regulations
- [CERTIFICATE OF CONFORMITY] T-REX-10KLP3G01 CEI 0-21 Cert
- [CERTIFICATE OF CONFORMITY] T-REX-10KLP3G01 CE-EMC Cert
